TYPE: VP-810WHD

10"HD MONITOR WITH DVR SUPPORT 1080P WHITE & INCLUD. EA001 GATE UNLOCK TYP: VP⁠-⁠810WHD

10
"10.1" color LCD touch panel 4-wire installation Intuitive interface Audio and video DVR recorder Internal communication Broadcast function Gate and wicket opening control Possibility to connect two CCTV cameras to one monitor Possibility to connect two external panels Calendar Alarm clock Electronic frame function Multimedia player You can save about 90 photos to the built-in memory MicroSD card reader supporting cards up to 128GB Manual screenshots and video recordings from the door station Leave message function (voice recorder) Automatic photo taking from the door station when called Motion detection and automatic video recording Automatic answer function when you are away It is possible to call up the doorphone or any CCTV camera at the user's request Two-way audio communication High resolution 1920x1080 image in HD quality A device without a headphone with a clear voice 10 levels of call volume control 10 levels of brightness, contrast and saturation adjustment 10 levels of melody volume control 13 polyphonic melodies Possibility to upload additional melodies to the microSD card Working temperature -30oC ÷ + 60oC Power supply 110-240V 50-60 Hz DC 14.5V / 0.8A Power consumption 9 W (Max), 2.5 W (standby) Operating humidity 0% - 95% Maximum installation length 100 m Monitor dimensions: 255x180x21 mm 772g "
Technical data
Colour Biały
Width 255 mm
Height 180 mm
Depth 21 mm
With On Screen Display Tak
Picture system Colour
Rated supply voltage 15 V
Power consumption during operation 9 W
Power consumption in standby mode 2,5 W
The operating temperature of the video monitor -30/60 °C
Working temperature -30/60 °C
On-demand monitoring time 420 s
Screen size 10 DPI
Resolution 1920x1080 DPI
Dimensions of the device 255x180x21mm mm
